Details
QO 15A Single-Pole CAFCI Circuit Breaker
This Square D QO combination arc-fault circuit breaker provides advanced protection against parallel and series arcs while safeguarding against overloads and short-circuits. Designed for QO load centers, it features Time-Saver Diagnostics and the Visi-Trip indicator for quick fault identification.
Key Features:
- Enhanced Arc Protection: Combination AFCI protects against parallel and series arcs to help prevent electrical fires
- Time-Saver Diagnostics: Built-in trip indication simplifies troubleshooting and speeds repairs
- Visi-Trip Indicator: Red handle position clearly shows the tripped breaker in crowded panels
- QO System Compatibility: Plug-on design fits QO load centers, CSEDs, and NQOD panelboards; requires 1 space
- Reliable Performance: 10kA interrupting rating, UL Listed, electronic trip unit for consistent protection
Please check the Product Data Sheet Here
Specifications Table:
| Specification | Details |
|---|---|
| Series | QO |
| Breaker Type | Standard, Combination AFCI |
| Poles | Single Pole |
| Maximum Amperage | 15A |
| Voltage | 120/240V AC |
| Interrupting Rating (AIC) | 10,000 A |
| Mounting Type | Plug-On |
| Spaces Required | 1 |
| Trip Unit | Electronic |
| Connection Type | Non-Neutral |
| Certifications | UL Listed |
| Product Dimensions | Height 4.76 in; Width 0.75 in; Depth 2.91 in |
| Product Weight | 0.57 lb |
| Warranty | Limited lifetime warranty for the lifetime of the QO load center in which installed |
Frequently Asked Questions (FAQ):
Q: Is this breaker compatible with my panel?
A: It is designed for Square D QO load centers, CSEDs, and NQOD panel boards; it is not compatible with Homeline or other brands.
Q: What voltage and amperage does it support?
A: Single-pole, 15A with 120/240V rating.
Q: Does it include a pigtail neutral lead?
A: Yes, it includes the coiled pigtail lead required for installation in QO panels.
Q: What certifications and warranty apply?
A: UL Listed; covered by a limited lifetime warranty for the lifetime of the QO load center in which it is installed.
Q: How do I identify a trip?
A: The Visi-Trip feature snaps the handle to a midpoint and shows a red indicator to quickly locate the tripped breaker.
Discreet Safety with Smart Diagnostics
In a refined home, protection should be as considered as the palette. This slim QO breaker tucks into your panel yet delivers intelligent arc-fault detection and a bold Visi-Trip cue for instant clarity. Pair it with a well-organized electrical layout to keep function elegant and unobtrusive. A quiet essential, it elevates everyday living with dependable, sophisticated safety.
Upgrade your panel with QO arc-fault protection and Time-Saver diagnostics for faster troubleshooting and safer circuits today.
