White Rodgers 16E09-101 Electronic Temperature Controller (24/120/208/240 Volts AC)

The White Rodgers 16E09-101 Electronic Temperature Controller (24/120/208/240 Volts AC) is a White Rodgers temperature controller for HVAC repair and replacement work. Use it when the part number 16E09-101 and the listed specifications match the equipment being serviced.

Superior Temperature Control and Accuracy for Both Refrigeration and Heating Applications...and It's Universal, Too! Specifications • Setpoint Range:-40° to 220°F (-40° to 104°C)• Differential Range: 1° to 30°F (1° to 30°C)• Supply Voltage: 24/120/208/240 VAC, 60Hz• Sensor: Negative Temperature Coefficient with 7.5-Ft. Leads (Maximum length for remote temperature sensing 400 feet)• Control Enclosure Ambient Temperatures• Operating: -29° to 140°F (-34° to 60°C)• Storage: -40° to 185°F (-40° to 85°C)• Cover and Case: NEMA 1 high-impact plastic• Thermoplastic: Non-flammable UL94V0• Switch Action: SPDT• Ambient Humidity: 0 to 95% RH…

Key Specs

• Temperature Range: 40° to 220°F
• Application: Refrigeration
• Switch Action: SPDT
• Product Type: Temperature Controller

Expert Verdict

Reviewed by the SuperArbor Pro Desk: choose this part when the existing component label and unit documentation match 16E09-101 and the spec set above. It is best suited for targeted HVAC service repairs where exact fitment matters more than broad universal compatibility.

FAQs

What is the White Rodgers 16E09-101 used for?

It is a temperature controller for compatible White Rodgers HVAC equipment. Match the part number 16E09-101 and the equipment service literature before ordering or installing.

Which specs should I verify before purchase?

Verify the spec set shown for this part: Temperature Range: 40° to 220°F; Application: Refrigeration; Switch Action: SPDT; Product Type: Temperature Controller. The replacement should match the existing component and the unit documentation.

How do I confirm this is the right replacement?

Compare the part number 16E09-101, the temperature controller description, and any unit model references with the original component and the service manual.

Is this an OEM-style replacement part?

Use it as a direct replacement only when White Rodgers documentation lists 16E09-101 or an approved equivalent for the unit being serviced.

Who should install this HVAC component?

A qualified HVAC technician should install and test the temperature controller. Disconnect power first, follow lockout procedures, and confirm safe operation after replacement.

Safety and Installation Notes

Disconnect power before service. HVAC electrical and combustion-related components should be installed and tested by a qualified technician. After installation, confirm wiring, mounting, airflow or fluid routing as applicable, and normal system operation.
